Dry Ball Mill

Production capacity：0.65-50t/h

Feeding Size：

Application：Dry ball mill production process does not need to add water, is a straight cylinder, but also installed with induced draft device, dust exhaust pipe and dust collector.

Description

Dry ball mill production process does not need to add water, is a straight cylinder, but also installed with induced draft device, dust exhaust pipe and dust collector. Our factory can design and manufacture other types and specifications of ball mills according to the requirements of users, and also according to the user's ore samples and output and particle size requirements, through grinding experiments and calculations, to determine the appropriate specifications of the type, design of the working state of the ball mill, so that it does not have insufficient function, and to ensure that the output and particle size requirements.

Process and Cost Advantages

The overall process may be simpler

For processes requiring a dry powder, the dry grinding process is: crushing → dry ball milling → classification → finished product.

For wet grinding, the process is: crushing → wet ball milling → dewatering → drying → classification → finished product. Dry grinding eliminates the critical intermediate slurry handling step, resulting in a simpler system.

Relatively low wear on grinding media and liners

In wet grinding, water and chemicals can accelerate corrosion and wear of steel balls and liners. In dry grinding, mechanical wear is the primary cause. For certain materials, overall wear costs may be lower than wet grinding.

Relatively low investment and maintenance costs

While dry grinding systems require an efficient dust removal system, their initial investment and ongoing maintenance costs may be more competitive in some cases compared to the complex slurry handling and dewatering equipment required for wet grinding, including concentrators, filters, dryers, pumps, and more.

Technical advantages

High quality castings
Our machines use high-quality materials and imported quality. Reduce the wear of accessories and increase the life of the machine.
Easy replacement of accessories
The lubrication system adopts polymer composite pipe, which effectively reduces the occurrence of oil leakage, and the novel design reduces the difficulty of installing parts.
Overload protection
When the unbreakable material falls into the crusher and the machine exceeds the normal load, the automatic stop device can automatically stop to avoid damage to the entire machine and ensure production safety.
Low noise and less dust
Through innovative R&D and design, our machine has the advantages of less dust, green and environmental protection, and passed the local environmental protection policy.

Technical parameters

Model	Cylinder speed (r/min)	Ball loading (t)	Feeding size(mm)	Output size(mm)	Capacity(t/h)	Power(kw)	Weight(t)
Ø900×1800	38	1.5	≤20	0.075-0.89	0.65-2	18.5	3.6
Ø900×3000	38	2.7	≤20	0.075-0.89	1.1-3.5	22	4.6
Ø1200×2400	32	3.8	≤25	0.075-0.6	1.5-4.8	45	12.5
Ø1200×3000	32	5	≤25	0.074-0.4	1.6-5	45	12.8
Ø1200×4500	32	7	≤25	0.074-0.4	1.6.5.8	55	13.8
Ø1500×3000	27	8	≤25	0.074-0.4	2-5	90	17
Ø1500×4500	27	14	≤25	0.074-0.4	3-6	110	21
Ø1500×5700	27	15	≤25	0.074-0.4	3.5-8	132	24.7
Ø1830×3000	24	11	≤25	0.074-0.4	4-10	180	28
Ø1830×6400	24	23	≤25	0.074-0.4	6.5-15	210	34
Ø1830×7000	24	25	≤25	0.074-0.4	7.5-17	245	36
Ø2200×5500	21	30	≤25	0.074-0.4	10-22	370	48.5
Ø2200×6500	21	31	≤25	0.074-0.4	14-26	380	52.8
Ø2200×7500	21	33	≤25	0.074-0.4	16-29	380	56
Ø2400×7000	21	34.5	≤25	0.074-0.4	18-32	400	62.8
Ø2400×8000	20.4	36	≤25	0.06-0.08	18-36	410	81.2
Ø2700×3600	18	37	≤25	＜0.08	50	410	77.5
